sad day...

(Image Source)

In case you haven't heard, Salt Lake lost a treasure today. 1547 Yale Avenue in the Yalecrest Historic District was torn down by the owner, Tom Hulbert. The home is right in the heart of the Historic District, a district that was the feature of the 2009 Utah Heritage Foundation Home Tour.

The home was purchased by the present owners in 2007, at the very same time the Yalecrest district received the designation from the National Register of Historic Places. From the owners website, they felt it was a "beautiful home" and desired to expand on the 2700 square foot home "by adding an addition to the rear of the home." If you click over to the owners website, you cannot read the text unless you highlight it for some reason. He goes through the decision-making process and attempts to defend his actions.

Apparently there were structural problems that needed to be addressed in this 1924 home. According to the engineers on the project, the cost to restabilize the home for another 80 years would have only been $150,000. The owner is not willing to pay that, but is willing to pay upwards of $1 million to build a new 7,200 square foot home? $100/square foot for a 7,200 square foot home will cost $720,000. And I doubt he will get the new home for that cheap.

The owners website documents what they want to do and why, but it all feels hollow and forced. He is thorough, but ultimately made a poor choice. What he and the community of Salt Lake lost is irreplaceable, no matter what home is built there now. In a historic district and neighborhood, there is almost always the option of restoration or new foundation work, which would be cheaper than starting over. And comparing the original home to the new design, well, there really is no comparison.


(Image source)

My number one question is: Why didn't he think to have an 85-year-old home checked out before purchasing to see if there were structural deficiencies and to confirm that he would be able to easily add onto it as was his original plan? THE HISTORIC HOMES AND UNIQUE ARCHITECTURE ARE THE ATTRACTION OF THIS NEIGHBORHOOD that he moved into. So he moves in and two years later has destroyed the very thing he purchased that helps make this neighborhood beautiful and unique! I truly do not understand.

To their credit, they actually tried to sell the home earlier this year. On the 28th of April 2009, the home was put on the market for $945,000. On the 11th of June 2009, the home price was reduced to $899,500. After 62 days, less than a month ago, it was taken off the market. According to the Salt Lake Tribune article, there was an $875,000 cash offer that they declined and opted to destroy the home instead and start over.

I love the remarks included in the real estate report when the home was on the market, “Curb appeal is unbeatable! Home has been prepared for total remodel.”


(Image source - Salt Lake Tribune)

Prior to receiving a demolition permit, a building permit was approved for the new home. While the new design at least has some sensitivity to the site, it is still a 7,200 square foot home. That’s quite an addition. So you mean to tell me that they would have been happy with their existing 2,700 square foot home purchase and a small addition in the back, even if there were no foundation problems? That’s a far cry from this new 7,200 square foot home. It sounds like this is what they wanted from the beginning. In todays slow high-end market, an $875,000 offer for the existing home was a good one. They could have taken it and built their 7,200 square foot home in almost ANY OTHER NEIGHBORHOOD IN UTAH and no one would have cared one bit. But instead they chose to destroy a treasure of the city in one of the few Historic Districts Salt Lake City has. What a travesty. What a loss. What a sad day.

City Wide Historic Preservation Master Plan
City Weekly article



View salt lake architecture in a larger map

upper main street buildings 1910-1911

Christmas News cover
Drawing by Ellis -----

This beautiful illustration shows the Templeton Building, Bishops Building, Deseret News Building, Vermont Building, Deseret Gymnasium, Salt Lake Temple, Hotel Utah, and the Pioneer Monument. Of the eight structures shown, only the Hotel Utah, Pioneer Monument, and Salt Lake Temple are still standing. I was unfortunately not able to find any information about the artist of this piece. (Image from Deseret Evening News 18 Dec 1909)

mount tabor lutheran church

The Mount Tabor Lutheran church simultaneously provides its sanctuary users with an intimate feel from the small footprint size, to a grand feel from the height of the volume above the altar. This height continually draws your gaze upward and allows abundant natural light to flow in from above. Amazingly, 240 people can fit in the six rows of seating, drawing everyone close to the ceremony. The classrooms are above the seating in the sanctuary and visually link to the main worship space through a series of slots beneath the circular glass tower. These slots open up to a circular corridor that serves all the classrooms. The six exposed angular wood columns visually and structurally link all three levels together.

Building Timeline
1959 - Decision to relocate the congregation from South Temple
1960 - Purchase of one acre site at 7th East and 2nd South
6 Jan 1963 - Groundbreaking
2 Jun 1963 - Cornerstone laid
Jul 1963 - Completed
8 Mar 1964 - Dedicated
1996 - Expansion of entrance areas, office space, handicap accessibility, and classrooms

The church was designed by retired architect Charles D. Peterson, a member of the congregation, who spent much of his career in Salt Lake, with an office in the Walker Building on Main Street. I had an enjoyable meeting with Charles at his Cottonwood home, where he was gracious enough to give me a blueprint copy of the plans and a section of the building. The first concept, as seen in the image and newspaper article below, was a hexagon. Later, the plan changed to a circle, which is what was eventually built. Another member of the congregation, Sig Zander, built the altar and pews.

From what I have been told, Mount Tabor has a strong music program and supports a number of ministries in the downtown area, including the St. Vincent de Paul Soup Kitchen, the Utah Food Bank, and Crossroads Urban Center.





Tabor Bears Plans for New Church
Salt Lake Tribune 14 Oct 1961

"A 'new look' in churches will grace the downtown area when the proposed $120,000 Tabor Lutheran Church is constructed on the northeast corner of 2nd South and 7th East.

Architect's sketches of the structure which has been in the planning stages for some time, were revealed Friday by the Rev. Arthur W. Sorensen, pastor.

An unusual, hexagon-shaped building, the new Tabor church will feature central seating in a semicircle around the altar, Pastor Sorensen said.

The seating plan will accommodate as many as 240 persons in only six rows, he added. The centrally located altar will be the focal point of the main floor of the two-story structure. A basement is also in the plans and will be used for a Fellowship Hall and Sunday School.

Eight classrooms will be built on the second floor, which will be a mezzanine-type arrangement overlooking the sanctuary. A large cross will hang suspended on wire from the ceiling of the church over the altar.

Other rooms in the church will include a kitchen, nursery, pastor's study and a parish worker's office.

The exterior will feature a multicolored glass tower and the lower part of the building will be a brick facing.

Designed by Charles D. Peterson, Architect, the structure will be only the first phase of the Tabor church's construction plans.

The church has been designed with the intent of expanding on the north end when the growth of the congregation warrants such a move.

Pastor Sorensen said he is planning ground-breaking ceremonies for early spring.

The present Tabor Lutheran Church is located at 61 E. St."


Preliminary hexagon design - image taken from Salt Lake Tribune 14 Oct 1961.


Main floor plan. Existing buildings have since been demolished and an additional wing has been added to the north side of the circular plan. From blueprint drawing of architect Charles Peterson.


Basement plan and 2nd floor plan. From blueprint drawing of architect Charles Peterson.


Section through building. From blueprint drawing of architect Charles Peterson.


Mt. Tabor's Specialty: 'Religion in the Round'
Salt Lake Tribune 26 Mar 1977

"One of Salt Lake City's more unique churches, at least from an architectural viewpoint, is Mt. Tabor Lutheran Church. 175-7th East, constructed in the round.

It's probably the only round church in Utah, said Mt. Tabor's pastor, the Rev. Elwyn D. Josephson.

The small church, which is almost as tall as the diameter of its sanctuary, is constructed as a circle. The foyer inside the north doors of the church is part fo the circle, and at each end of the foyer are entrances to the sanctuary.

The sanctuary is designed in the round, with wood pews nearly surrounding the free-standing altar, one of the focal points in the sanctuary and, said Pastor Josephson, one of the items traditionally emphasized in the Lutheran Church.

He said Mt. Tabor, built 15 years ago, is not particularly unusual in architectural design. He pointed out there has been a departure from the traditional rectangular design within the Lutheran Church during the past 20 years.

During this period, he said, more and more churches being built varied from the traditional church designs.

'The purpose of these variations, such as round or even some triangular structures, has been to focus more attention on the altar,' Pastor Josephson said. 'And many of these altars are free-standing, centrally located ones.'

Building a round church is not unprecedented, either, he said. Some Lutheran churches in Denmark were built in the round and Roman basilicas in the 2nd and 3rd centuries were in the round.

'The focus in Lutheran churches is always twofold,' the clergyman said. 'The first emphasis is on the sacraments, the baptismal font and the altar, where Holy Communion is celebrated. The second focus is on the pulpit, because that is where the Word is preached.'

Mt. Tabor's tall dome, surrounded mostly by glass windows, was also built for a purpose, Pastor Josephson said.

'Height tends to elevate the worshipers' thoughts and hearts to God. It tends to add majesty and instill the feeling of majesty and awe in the worshipers,' he said.

There are also certain advantages to the round church itself, the pastor said.

'By being surrounded, a great sense of warmth, intimacy and fellowship in worship is provided,' explained Pastor Josephson.

Mt. Tabor hosts has about 150 members, the pastor said. Eight or nine years ago, it had more than 400 members, but he said the church has suffered from the same problems that plague many downtown churches.

'Families will transfer out of the area and when new people move in, they move to the suburbs rather than to the city because the houses are in the suburbs,' Pastor Josephson said."


Large multi-purpose space in basement with walk-out to sunken exterior patio. Notice the angled structural columns carrying through to the sanctuary above and supporting the circular roof. Exposing the wood structure in this manner provides an ever-present connection to the sanctuary above.


Sunken patio off of 2nd south with link to basement doors.


Additional entry and classroom wing expansion from 1996.




Upstairs in circular corridor surrounding the double-height sanctuary. Linear window slots and exposed angled wood columns provide connection to the sanctuary. Corridor provides access to classroom spaces.


Circular sanctuary seating with structural wood column supporting classrooms and glass tower above.

dreier home

This fantastic home off Mueller Park Road in Bountiful was designed by the late Eduard Dreier over 30 years ago, sometime in the 1970's. The home addresses the site and the region it is built in. The home uses thermal massing by placing the large fireplace in the center of building. From this, the home is able to remain cool in the summer and warm in the winter. There is generous glazing on the south facade with large overhangs to block the high summer sunlight but allow in the low winter light. The original owner who commissioned the design still lives there. Unfortunately, they never agreed to have the home published. I wasn't able to get inside, but the owner was kind enough to let me walk around the property.


Large overhangs protecting home from south-facing summer light. Photo taken from bridge walkway over a stream leading to the entry.


South facade of home.

As you can see, the home is part of the landscape, does not feel intrusive, and seems to belong to the land - as a natural extension. It fits in to the surrounding context in which it is placed; it is not forced or arrogant. The home is interested in seeing and understanding, not in being seen or understood. Compare this to the McMansions being built up the hill. These homes want to be seen and stand out. They are cookie-cutter houses you can find anywhere in America. The Dreier home is a home designed specifically for the Utah climate by a local architect with minimal impact on the surrounding community. In contrast, McMansions are designed by builders and graze down or force a community where they shouldn't be one; in this case on the top of a hill.


McMansions being built up the hill from home.


Landscaped steps leading from stream up to home.


Front of home.

joseph f smith building

Constructed with the theme of “light and truth,” the modern glass facade of the building’s main entrance contrasts with a cloistered inner courtyard featuring a fountain. The glass-enclosed gallery, a beautiful, light-drenched space, is designed to house a series of exhibits that will expand on the educational experiences offered in the building. (BYU Today, Fall 2005)

Joseph F Smith Building
Brigham Young University Campus-Provo, UT
Architect: FFKR
Size: 280,000 SF, 5 story
Construction Began: 3 Jun 2002
Dedication: 20 Sep 2005


Entry to courtyard


Inner courtyard perimeter

Paid for through private donations, the building will feature 27 classrooms, 401 faculty and administrative offices, a large auditorium, a theater, and a three-level, 265-stall underground parking lot. The new building will contain more than double the square footage of its predecessor on a smaller footprint.

The building is intended to function as a work of art that sends a visual message, says Van C. Gessel, dean of the College of Humanities. "The architectural concept emphasizes light as the source of any kind of knowledge and learning. Education at BYU is very much about the light that comes from the Spirit."

To bring natural light into as many offices and public areas as possible, the architectural firm of FFKR designed the building around a central landscaped courtyard. A massive two-story glass gallery will grace the main entrance on the east, and generous use of glass throughout will permit light to enter much of the facility, including some of the basement. (BYU Today, Summer 2002)



Inner courtyard landscaping and benches


Sun screen shading device on west facade in courtyard


Close-up of sun screen shading device

I was pleasantly surprised by this building and my overall critique is a positive one. All buildings send a visual message, whether intended or not, so what type of message you are sending becomes the goal to think about and explore. I was glad to see the theme of ‘light and truth’ as a design guide for this project.

Unfortunately the theme appears to largely have been a missed opportunity with this building. As an unattached bystander, very little about the building says to me light or truth more than other buildings. I would have liked to see the theme pushed further. There is an inconsistent handling of light control. When speaking about light, the treatment of the south facade should be completely different from that of the north facade, and this building treats them the same.

Also, it’s not just about flooding the building with as much natural light as possible as was mentioned above. What do you do with that light? How do you harness, channel, and distribute that light to the occupants? What do the ‘light features’ teach the occupants of the building about knowledge and education? How could the building itself become an actual symbol of light and truth? Exploring this in built form could inform a spiritual yearning for harnessing, channeling, and utilizing a spiritual light in education.


Gallery spiral stair


Gallery spiral stair

What was done beautifully is applying the program of housing the College of Family, Home, and Social sciences into the design. The LDS Church views the family as sacred and is very protective of the institution of marriage and the family. This building supports that belief. The mostly non-descript exterior of the building acts as a protective wrapper providing an inner courtyard where the real beauty of the building lies. Here, the best design and materials have been used. Here, the beautiful landscaping creates a relaxed, welcome, and soothing environment. The building surrounding on all sides creates a sense of safety and intimacy. This protected enclave for study, discussion, or relaxing is symbolic of the role the College hopes to play relating to the family.

The wrapping and enclosing concept is further reinforced in the beautiful and striking circular gallery stair prominently located as one of the main features of the building. Similar to the courtyard, this feature of the building really draws you in with a desire to experience the space. This links nicely with the College also, where teachings about the family will draw you in and be provided with a protective enclosure, allowing interdisciplinary teachings about the family to come together into one place.

The final example of wrapping and protective enclosure is at a smaller, more intimate scale of a series of six gathering spaces in front of the building, using landscaped circular seating in concrete and vegetation.


Gallery spiral stair


Gallery spiral stair


Gallery spiral stair

Where I get lost in the metaphor at the gallery stair is being drawn from the lower level to the light above, when most of the classrooms and teaching occur at the lower level, not up where the light is. The light is taking you away from where you are learning.

Finally, there are some beautiful details that were fortunately not removed for budgetary considerations, such as the exterior curtain wall extensions and the wood cubicles over some of the interior doors.




One of six gathering spaces in front of the building that reinforces the courtyard and spiral stair concept of wrapping and protective enclosure.

*All images taken by author on 13 Jun 2009


View salt lake architecture in a larger map

prairie style in utah

Malcolm A Keyser House 381 East 11th Avenue, Salt Lake City

Did you know that Utah has one of the highest concentrations of Prairie Style buildings outside of the Midwest? Early Utah architects embraced the new designs and executed buildings all over the state. The website, Prairie School Traveler, has compiled an impressive 84 buildings in Utah built in this style. Out of the 39 states and 6 countries listed, Utah places 6th in quantity of prairie-style buildings behind Illinois, Wisconsin, Iowa, Minnesota, and California. Salt Lake City alone has 47 buildings listed, placing it 7th in the country behind Chicago, Oak Park, Minneapolis/St Paul, San Jose, Milwaukee, and Jacksonville. Not that these numbers really matter, but they help illustrate that there are a great number of these beautiful buildings all within a short drive for us to experience and enjoy.

Has there ever been a Prairie-Style Parade of Buildings for SLC? If not, we definitely should do one.


Caithness Apartments (now Caithness Condominiums) 86 B Street, Salt Lake City


Gustave L Becker House 2408 Van Buren Avenue, Ogden
See here for a 1918 photo of house

I am in process of locating each of these 84 buildings and identifying them on the sidebar map. For easy identification, they are shown with green markers.

# on National Register of Historic Places - 6
# Demolished - 9

Known Prairie-style Architects with buildings in Utah:
-Shreve & Madsen
-Pope & Burton
-Ware & Treganza
-Fred W. Hodgson
-Leslie Hodgson
-Eber Piers
-Miles Miller
-Taylor Woolley
-Cannon & Fetzer
-Scott & Welch
-Monson & Price
-Olaf Nielsen?
-J.C. Craig
-Avery Timms

*Photographs above from The Prairie School Traveler, courtesy of Butch Kmet.

architects in slc 1867-1880

Over the 13 year period from 1867-1880, there ranged from one to seven people in the city who called themselves architects.

1867 Salt Lake City Directory
(No specific employment listings. From looking up names from the 1869 architects, the following was found.)

• Cram, Charles S., Architect, office at old City Hall, residence 7th Ward, southwest corner of 1st West and 5th South

• Angell, T.O., Carpenter, 14th Ward, rear north side 1st South between East Temple and 1st East
• Evans, Samuel L., Stone cutter, residence 6th Ward, west side of 4th West between 4th and 5th South

1869 Salt Lake City Business Directory
Architects.

• Albion, James, 15th Ward 1 South between 4 and 5 West
• Angell, T.O. 1st Ward
• Cram, Charles S. 7th Ward 5 South corner 1 West
• Evans, S. S. 4 West between 4 and 5 South
• Folsom, W.H. South Temple corner 1 West
• Paul, William, Garden, corner Locust
• Walling, Warren, “Sugar House Ward,” County road


1874 Salt Lake City Business Directory
Architects.

• Angel, Trueman O., office Temple block
• Harrison, E.L.T., Bellview terrace
• Manheim, H., 78 East Temple east side
• Taylor, Obed, Matthiessen’s block, East Temple


Architects and Builders.

• Folsom, W.H., corner 1 West and South Temple
• Paul, Wm., Sr., corner of Garden and Locust
• Paul, Wm., Jr., South Temple between 2 and 3 West


1879-80 Salt Lake City Business Directory
Architects.

• Angel T O, southwest corner 1 East and 6 South
• Folsom, W H, southwest corner 1 West and South Temple
• Harrison, E L T, Belleview Terrace, 19 ward
• Monheim, Henry, east side East Temple between 1 and 2 South
• Paul, Wm, corner Garden and Locust
• Taylor, Obed, over Deseret Bank




(First Architect advertisement in SLC)
